Four input channels allow direct connection to stereo keyboards, laptops, electronic drums, sound modules and microphones, making it the most compact mixer/speaker solution in the Traynor line. A handy link function allows two Block12 amplifiers to be connected for stereo operation with double the input channels.
Designed for maximum versatility, the Block12 uses a combination box design that allows the cabinet to operate in an upright position for small PA applications, or in a wedge format for use as a monitor. A solid plywood cabinet construction, black carpetcovering, and a curved, perforated all-metal grille ensure unmatched long-term reliability. Integrated standmount adaptor allows the Block12 to be used on a standard speaker stand for added versatility.
Specs:
• Cabinet Program Power (Watts): 200
• Speaker Configuration - LF (Size / Power): 12-inch/200 watts
• Speaker Configuration - HF (Size / Power): 1-inch /50 watts
• Frequency Response (Hz +/-3dB): 20 - 20k
• Inputs: 4
• Channel 1 - Inputs: 2 x 1/4-inch
• Channel 1 - Controls: Gain, 2 band EQ
• Channel 2 - Inputs: 1/4-inch/XLR
• Channel 2 - Controls: Gain, 3 band EQ
• Channel 3 - Inputs: Stereo 1/4-inch, Stereo 3.5mm
• Channel 3 - Controls: Gain
• Channel 4 - Inputs: Mono, ¬-inch
• Channel 4 - Controls: Gain
• Master Volume Control: Yes
• Input Sensitivity (mV): 250
• Line Out (type / configuration): Balanced XLR (Pre/Post EQ, Pre Master)
• Line Out Sensitivity (Vrms): 1 Vrms
• LED Indicators: Power, Ch. 1-3 Clip
• Protection: Thermal
• Dimensions (DWH, inches): 14.3 x 21.25 x 14.65
• Dimensions (DWH, cm): 36.5 x 54 x 37.5
• Weight (lbs / kg): 33.5 / 15.2
• Specifications subject to change without notice
